Description
xBody 6061-T6 Anodized Aluminum
Driver 7075 Aluminum (hard anodized) shimano compatible
6 pawls w/ 80T ratchet
Sealed roller bearings / front hub 2x / /rear hub 4x /
Alu axle 10 mm diameter ( mini ) w/ M5 bolts
Alu axle 15 mm diameter ( pro ) w/ 10 mm bolts
Steel bolts
Front:
100mm
Flange to Flange 72 mm
Flange Dia (center hole to center hole) 47 mm
Hole dia 2.5 mm
Weight 115g mini w 133g w bolts
Weight 190g pro w 10 mm bolts
Rear:
110 mm
Flange to Flange 55 mm
Flange non drive side 45 mm
Flange drive side 58 mm
Non drive side to flange 26 mm
Drive side to flange 26 mm
Pro: 40 mm bolts M10 x 1.0
Weight 297g w/o bolts
Mini: 30 mm bolts M5
Weight 287g w/o bolts
Centerlock disc brake w alu lock ring
Driver alu 7075 w 10 mm cog space and alu lock ring
6 pawls
60T ratchet
3 sealed bearings
